Place of Origin: | China |
Brand Name: | RJ TECH |
Certification: | MSDS/UN38.3/ROHS/CE/KC |
Model Number: | RJ-LFP16K |
Minimum Order Quantity: | 1pcs |
---|---|
Price: | USD1-100/pcs (FOB Shenzhen) |
Packaging Details: | Wooden packing+Tray |
Delivery Time: | 7days |
Payment Terms: | TT |
Supply Ability: | 100000pcs |
Material: | Lithium Battery (LiFePO4) | Capacity: | 16kwh |
---|---|---|---|
Cycles: | > 9000times | Warranty: | 20 Years |
Installation: | Wall Mounted | Voltage: | 51.2V |
9000CYCLES - 20YEARS WARRANTY - FACTORY PRICE
Product Features:
Compatibility
SMA/Victron/Sol-ark/Deye/Growatt/Goodwe/Schneider/Solis/SolaX/Sofar/Voltronic/East/Kehua/Kostar/Studer/sunsynk/Luxpower
Top Quality & Powerful
CATL prismatic cells, brand new, grade A
Outstanding >9000cycles @ 100%DOD
Excellent 20years full warranty
Plug & Play, WIFI APP WEB Monitor
Safe & Reliable
UL1973 UL9540 UL9540A IEC62619 UL1741, CE
No | Items | Value | Remark |
Cell unit | |||
1 | Battery types and materials | LiFePO4 | |
2 | Rated voltage/capacity | 3.2V 314Ah | CATL |
3 | Single battery voltage range | 2.5V~3.65V | |
4 | Single battery weight | 5Kg | |
5 | Battery internal resistance | ≤ 0.6mΩ | |
6 | Battery Cell Size | 72*174*204mm(L*W*H) | |
Battery Module | |||
1 | Rated voltage | 51.2V | |
2 | Rated capacity | 314Ah | |
3 | Battery pack voltage range | 44.0V~58.4V | |
4 | Battery energy | 16kWh | |
5 | Combination | 1P32S | |
6 | Insulation resistance test value | ≤20MΩ | |
7 | Charging temperature | 0 ~ 45℃; | |
8 | Discharging Temperature | -20 ~ 60℃ | |
9 | Standard charging current | ≤200A | |
10 | Standard discharge current | ≤200A | |
11 | Net weight | ~130KG | |
12 | Battery size | 630*500*850mm | |
13 | Installation Method | Wall mounted | |
14 | Communication | RS485/CAN/RS232 |
