12000CYCLES - 20YEARS WARRANTY - FACTORY PRICE
Product Features:
Compatibility
AC couple to retrofit existing solar system & DC coupled capability
Max 32 pcs parallel for on-grid and off-grid
Manage all the energy sources Solar + Wind + Storage + Grid + Generator
Top Quality & Powerful
CATL prismatic cells, brand new, grade A
Outstanding >9000cycles @ 100%DOD
Excellent 20years full warranty
Plug & Play, WIFI APP WEB Monitor
Safe & Reliable
UL1973 UL9540 UL9540A IEC62619 UL1741
IEC/EN 61000-6-1/2/3/4, IEC/EN 62109-1, IEC/EN 62109-2
| No |
Items |
Value |
Remark |
| Inverter Module |
| 1 |
AC Voltage |
120/240Vac; 208Vac |
Deye brand |
| 2 |
Feed in type |
split / 3 phase |
both supported |
| 3 |
Grid Frequency |
50/60HZ |
auto sensing |
| 4 |
Max Continuous Power |
12000W |
grid & UPS |
| 5 |
Max Peak Power |
24000W |
10s |
| 6 |
Nominal Grid Current |
50A |
|
| 7 |
Max PV Input Power |
15600W |
|
| 8 |
MPPT Voltage Range |
125-500Vdc |
|
| 9 |
Max. Input Short-Circuit Current |
44+44+44A |
|
| Battery Module |
| 1 |
Rated voltage |
51.2V |
|
| 2 |
Rated capacity |
161.5Ah |
CATL |
| 3 |
Total Energy |
≥8.3kWh |
|
| 4 |
Charging temperature |
0 ~ 45℃； |
|
| 5 |
Discharging Temperature |
-20 ~ 60℃ |
|
| 6 |
Charging current |
≤100A |
|
| 7 |
Discharge current |
≤100A |
|
| 8 |
Net weight |
70KG |
|
| 9 |
Battery size |
620*425*230mm |
|
| 10 |
Installation Method |
Stackable |
|
| 11 |
Communication |
LCD, LED, RS485, CAN, Wi-Fi, GPRS, 4G |
|
| 12 |
Parallel connection |
Max 16pcs |
64pcs optional |
