9000CYCLES - 20YEARS WARRANTY - FACTORY PRICE
Product Features:
Compatibility
SMA/Victron/Sol-ark/Deye/Growatt/Goodwe/Schneider/Solis/SolaX/Sofar/Voltronic/East/Kehua/Kostar/Studer/sunsynk/Luxpower
Top Quality & Powerful
CATL prismatic cells, brand new, grade A
Outstanding >9000cycles @ 100%DOD
Excellent 20years full warranty
Plug & Play, WIFI APP WEB Monitor
Safe & Reliable
UL1973 UL9540 UL9540A IEC62619 UL1741
IEC/EN 61000-6-1/2/3/4, IEC/EN 62109-1, IEC/EN 62109-2
| No |
Items |
Value |
Remark |
| Cell unit |
| 1 |
Battery types and materials |
LiFePO4 |
|
| 2 |
Rated voltage/capacity |
3.2V 50Ah |
CATL |
| 3 |
Single battery voltage range |
2.5V～3.65V |
|
| 4 |
Single battery weight |
1.3Kg |
|
| 5 |
Battery internal resistance |
≤ 0.6mΩ |
|
| 6 |
Battery Cell Size |
30*135*180mm(L*W*H) |
|
| Battery Module |
| 1 |
Rated voltage |
102.4V |
|
| 2 |
Rated capacity |
50Ah |
|
| 3 |
Battery pack voltage range |
44.0V～58.4V |
|
| 4 |
Battery energy |
5.12kWh |
|
| 5 |
Combination |
1P32S |
|
| 6 |
Insulation resistance test value |
≤20MΩ |
|
| 7 |
Charging temperature |
0 ~ 45℃； |
|
| 8 |
Discharging Temperature |
-20 ~ 60℃ |
|
| 9 |
Standard charging current |
≤50A |
|
| 10 |
Standard discharge current |
≤50A |
|
| 11 |
Net weight |
~49KG |
|
| 12 |
Battery size |
630*185*345mm |
|
| 13 |
Installation Method |
Stackable |
|
| 14 |
Communication |
RS485/CAN/RS232 |
|
| 15 |
HV Box voltage range |
150-600Vdc |
|
| 16 |
HV Box weight |
~20KG |
|
| 17 |
Battery Series connection |
Max 5pcs |
limited by weight |
| 18 |
HV Box Parrallel connection |
Max 4set |
|
| Combination |
| 1 |
2pcs x battery + 1pcs x HV box |
204.8V 50AH 10.24KWH |
|
| 2 |
3pcs x battery + 1pcs x HV box |
307.2V 50AH 15.36KWH |
|
| 3 |
4pcs x battery + 1pcs x HV box |
409.6V 50AH 20.48KWH |
|
| 4 |
5pcs x battery + 1pcs x HV box |
512V 50AH 25.6KWH |
|
