Powerwall Home Battery-3.5KWH-5KWH-7KWH-10.5KWH-20KWH,
Lithium House Battery ESS Energy Storage
RJ Powerwall Home Battery Manufacturer
5kwh powerwall battery 7kwh powerwall battery
10kwh powerwall battery Type A 10kwh powerwall battery Type B
10kwh powerwall battery Type C 20kwh powerwall battery
30kwh powerwall battery 40kwh powerwall battery
50kwh powerwall battery
With Powerful capacity of Powerwall Home Battery production, RJ is able to provide
1 to 1 customization service. No matter you only buy 1 pcs battery for your own use,
or you are a company looking for bulk order of Powerwall Home Battery, RJ will always
meet your full satisfactions!
| Model |
RJ5K |
RJ7K |
RJ10K |
RJ15K |
| Norminal Power(KWh) |
5 KWh |
7Kwh |
10 KWh |
15Kwh |
| Norninal Capacity(Ah) |
100Ah |
150Ah |
200Ah |
300Ah |
| Norninal Voltage(V) |
48V-51.2V |
48V-51.2V |
48V-51.2V |
48V-51.2V |
| Material Type |
Lithium Battery (LiFePO4) |
Lithium Battery (LiFePO4) |
Lithium Battery (LiFePO4) |
Lithium Battery (LiFePO4) |
| Dimensions (mm) |
|
|
670 x 165 x 580 mm |
|
| Weight(Kg) |
50 Kg |
70kg |
100 Kg |
150Kg |
| Discharging Voltage(V) |
40~58.4 V |
40~58.4 V |
40~58.4 V |
40~58.4 V |
| Max Charging |
100A |
100A |
100A |
100A |
| Continuous Discharging (A) |
100A |
100A |
150A |
200A |
| Peak Discharging (A) |
200A |
200A |
300A |
400A |
| Expansibility |
100KWh |
100Kwh |
100KWh |
100KWh |
| Installation Methode |
Wall / Floor Mounted |
Wall / Floor Mounted |
Wall / Floor Mounted |
Floor Mounted |
| Communication Port(Optional) |
RS485 / Bluetooth |
RS485 / Bluetooth |
RS485 / Bluetooth |
RS485 / Bluetooth |
| Working Temperature(℃) |
-20~75℃ |
-20~75℃ |
-20~75℃ |
-20~75℃ |
| Humidity |
0-95% RH |
0-95% RH |
0-95% RH |
0-95% RH |
| IP Grade (IP) |
0-95% RH |
0-95% RH |
0-95% RH |
0-95% RH |
| Altitude |
≤3000m |
≤3000m |
≤3000m |
≤3000m |
| Authentication Level |
TuV/CE/UN38.3 |
TuV/CE/UN38.3 |
TuV/CE/UN38.3 |
TuV/CE/UN38.3 |
| Design Life(year) |
20+ years |
20+ years |
20+ years |
20+ years |
| Cycle Life (cycle) |
>6000Times (100%DOD) |
>6000Times (100%DOD) |
>6000Times (100%DOD) |
>6000Times (100%DOD) |
| Model |
RJ20K |
RJ30K |
RJ40K |
RJ50K |
| Norminal Power(KWh) |
20 KWh |
30 KWh |
40KWh |
50 KWh |
| Norninal Capacity(Ah) |
400Ah |
600Ah |
800Ah |
1000Ah |
| Norninal Voltage(V) |
48V-51.2V |
48V-51.2V |
48V-51.2V |
48V-51.2V |
| Material Type |
Lithium Battery (LiFePO4) |
Lithium Battery (LiFePO4) |
Lithium Battery (LiFePO4) |
Lithium Battery (LiFePO4) |
| Dimensions (mm) |
670 x 165 x 580 mm * 2pcs |
610*800*1600mm |
610*800*1100mm *2pcs |
610*800*1500mm *2pcs |
| Weight(Kg) |
200 Kg |
300 Kg |
400 Kg |
500 Kg |
| Discharging Voltage(V) |
40~58.4 V |
40~58.4 V |
40~58.4 V |
40~58.4 V |
| Max Charging |
100A |
120A |
160A |
200A |
| Continuous Discharging (A) |
200A |
300A |
400A |
500A |
| Peak Discharging (A) |
400A |
600A |
800A |
1000A |
| Expansibility |
100KWh |
100KWh |
100KWh |
100KWh |
| Installation Methode |
Wall / Floor Mounted |
Rack Mounted |
Rack Mounted |
Rack Mounted |
| Communication Port(OPTIONAL) |
RS485 / Bluetooth |
RS485 / Bluetooth |
RS485 / Bluetooth |
RS485 / Bluetooth |
| Working Temperature(℃) |
-20~75℃ |
-20~75℃ |
-20~75℃ |
-20~75℃ |
| Humidity |
0-95% RH |
0-95% RH |
0-95% RH |
0-95% RH |
| IP Grade (IP) |
0-95% RH |
0-95% RH |
0-95% RH |
0-95% RH |
| Altitude |
≤3000m |
≤3000m |
≤3000m |
≤3000m |
| Authentication Level |
TuV/CE/UN38.3 |
TuV/CE/UN38.3 |
TuV/CE/UN38.3 |
TuV/CE/UN38.3 |
| Design Life(year) |
20+ years |
20+ years |
20+ years |
20+ years |
| Cycle Life (cycle) |
>6000Times (100%DOD) |
>6000Times (100%DOD) |
>6000Times (100%DOD) |
>6000Times (100%DOD) |
1. Quick delivery
Fast delivery is key factor for clients to compete in the market. We attach much importance to quick delivery
as much as we do in our Powerwall home battery quality. We will keep our clients updated with tracking number
all the time and latest tracking info until the order of Powerwall home battery arrives at our clients safely.
2. Top quality
As a Powerwall home battery Manufacturer for over 16years in China, We have been devoting ourselves into
innovative R&D of Powerwall home battery, Top quality is what makes RJ distinguished in todays market and
what earns RJ a highly reputation in the international market of Powerwall home battery.
3. Customization Available
We can help customize the charge and discharge characteristics of Powerwall home battery to meet your specific
needs, and We can print your company logo on the LifePO4 battery to help advertise your company in the market
4. 7*24 service
Timely and reliable customer service is very important to our clients, which will influence a smooth relationship
establishment. Therefore, we are and will always provide very Professional Pre-sales as well as Whole-hearted
after-sales service for 24hours a day, 7days a week.
5. Reliable Warranty
We offer 10years warranty for Powerwall home battery. If any defective LiFepo4 battery occur, we will send you
a brand new one free of charge, and you do not need to return the defective one because we understand the
international shipping fee is too expensive. RJ believe when we do our service with whole heart, We will earn our
customers trust and earn our high reputation back!
