Lithium Battery 12 Volt 80Ah Li ion Battery LiFepo4 For Drop-in
Replacement SLA
FAQ
1. How long of your 12 volt lithium battery can I expect?
Under normal situation, that is, discharge at less than 2C, 100%DOD, our 12 volt lithium battery can reach as many as 6000cycles. If one cycle, discharge and charge, per day, which means 365cycles per year, then lifespan of our lithium battery can be at least 20years. This is the great advantage of lifepo4 battery and why our 12 volt lithium battery is a perfect substitute for lead acid, AGM, Gel battery.
2. I already have a SLA controller, I want to charge the lithium battery with it, is it possible?
Yes, most of the case, it should be fine, specifically speaking, for our 12V lithium battery, the charging voltage is 14.6V, many SLA contoller has such a voltage too, that should be fine. We also know that some SLA controller in the market has a pulse current when charging, this won’t affect the completion of charging to the lithium battery, but the pulse may cause some bad impact on the lithium battery, and in the long run it might not be good to lithium battery. So you had better contact us for confirmation before you charge our 12 volt lithium battery with your existing lead acid battery charger. We can help check it out and make sure it is no problem.
3. Can you tell more about 12V ltihum battery with Bluetooth Monitoring?
We have already developped a completed system with bluetooth monitoring technology. Which includes an app on the smart phone supporting IOS or Android phone. The communication between the battery and the app on phone is wireless, no need for any other connection. It is very popular and fashionable in use, you can even share the status of your battery operation in the social network like facebook, instagram or twitter etc. contact us now, we can send you a link for download this app, you can try it on now.
| Items |
Parameter |
| Battery Type |
LiFePO4 |
| Nominal Voltage |
12.8V |
| Nominal Capacity |
80Ah |
| Energy |
1024Wh |
| Limited Charge Voltage |
14.6±0.2V |
| Floating Charge Voltage |
13.8±0.2V |
| Charge Method |
CC/CV |
| Discharge Cut-off Voltage |
10.0V |
| Standard Charge Current |
60A |
| Standard Continuous Discharge Current |
60A |
| Max. Continuous Discharge Current (<10min) |
120A |
| Cycle Life |
> 6000 cycles |
| Dimension (mm) |
Length: 232±2 Width: 171±2 Height: 215±2 |
| Weight |
12.5±0.2Kg |
| Charge Temperature Range |
0~45℃ |
| Discharge Temperature Range |
-20~60℃ |
| Recommended Operating Temperature |
15~35℃ |
| |
|
Built-in BMS
| No. |
Item |
Test Item |
Creterion |
| 1 |
Voltage |
Charging Voltage |
DC:14.4V CC/CV |
| Balance voltage for single cell |
3.50±0.025V |
| 2 |
Current |
Balance voltage for single cell |
35±5mA |
| Current consumption |
≤50μA |
| Charging current |
60A |
| Rated continuous discharging current |
60A(Peak 120A) |
| 3 |
Over charge Protection |
Over charge detection voltage for single cell |
3.65V±0.025V |
| Over charge detection delay time |
0.7S—1.3S |
| Over charge release voltage for single cell |
3.550±0.05V |
| 4 |
Over discharge Protection |
Over discharge detection voltage for single cell |
2.50V±0.07V |
| Over discharge detection delay time |
1.6±0.5S |
| Over discharge release voltage for single cell |
3.00±0.75V |
| 5 |
Over current Protection |
Over current detection current |
500±50A |
| Over current detection delay time |
1.6±0.5S |
| Release condition |
Cut load |
| 6 |
Short Protection |
Detection condition |
Exterior short circuit |
| Detection delay time |
230uS—500uS |
| Release condition |
Cut load |
| 7 |
Resistance |
Protection circuitry (MOSFET) |
≤60mΩ |
| 8 |
Temperature |
Operating Temperature Range |
-40~+85℃ |
| Storage Temperature Range |
-40~+125℃ |
Application :
1. Our battery is perfect for Telecom-base,E-Bike,EV,smart robot,miner lamps,etc
2.Customizable lithium battery: Low speed vehicles, forklift, golf car, E-scooter
3.Medical equipment: emergency lighting system, hospital backup power engergy storage,B-machine, anesthesia machine etc.
4.AGV Robot: Industrial Robot for logistics , Service Robot for restaurant, Educational Robot for school, Clean Robot for househole, Entertainment Robot for young people, Lithium LiFePO4 Battery Pack
5.Energy storage: solar off grid energy storage system, wind power, UPS for data center, computer backup power supply, backup power, AGV, yachts, etc.
6.Portable power: RV camper, Caravan, battery with inverter and solar charger, outdoor portable power, etc.
