LiFePO4 Lithium Battery 12 volt 100Ah 6000Cycles For RV Caravan
Camper
Feature of 12Volt lithium battery
Our 12V lithium battery is Powerful, which is perfect for RV, Camper, Trailer, Marine Boat, Solar Energy Storage. Also it is very powerful for Golf car, EV, AGV and E-forklifts.
RJ 12 v lithium battery has more enegy than Lead Acid or Gel or AGM battery.
- Lifepo4 Chemistry: The safest , longest lifecycles and most powerful of all kinds of lithium ion battery in the market.
- Buil-in BMS : All 12v lithium battery comes with a built-in BMS inside, high Quality BMS protect the battery against over-charge, over-discharge, overheat, over current , and short circuit. It can be put in use as in Series up to 4 batteries, which is 12V, 24V, 36V and 48V.
- LED Indicator: Our 12v lithium battery can be customized and built with a capacity and voltage display. Which is convenient when you need to monitor the operation of 12 volt lithium battery.
- Prismatic Cells: Our Batteries adopt newest technology from German and Japan, and it is manufactured in China, with the great advantage of cost in China, We are able to provide you the most competitive price in the market, we provide 5years on our 12 volt ltihum battery.
- Best Energy Storage Solution: our 12V lithium battery will be the no.1 best solution for your RV, or Marine boat of solar energy storage system. more powerful than any Agm, gel, or Lead Acid battery,above all, it is nearly with 1/3 less weight 10 times longer in lifecycles when compared with a Lead Acid battery or AGM battery. It might comes with a higher price , but in the long term, it is much more economic to buy our LiFePO4 12 volt lithium battery.
- Best Replacement for Golf Cart: Our 12V lithium battery can perfectly replace any 24V, 36V and 48V battery directly for any type of Golf Cart, AGV, EV, long hours lasting, free of maintenance and long lifetime is what you have been looking for, then you absolutely can not miss our 12V lithium battery, this is a perfect solution to your needs. The outstanding feature of our lithium battery will not only make your RV, marine boat , solar system more powerful, more robust, but also faster , lighter and fashionable!
Specification of 12V 100Ah Lithium battery
| ItemsItems |
Parameter |
| Battery Type |
LiFePO4 |
| Nominal Voltage |
12.8V |
| Nominal Capacity |
100Ah |
| Energy |
1.28KWh |
| Internal Resistance |
≤20mΩ |
| Series & Parallel Application |
up to 4 series 4 parallel connected application |
| Limited Charge Voltage |
14.6±0.2V |
| Floating Charge Voltage |
13.8±0.2V |
| Charge Method |
CC/CV |
| Discharge Cut-off Voltage |
10.0V |
| Standard Charge Current |
20A |
| Max. Charge Current |
100A |
| Standard Continuous Discharge Current |
100A |
| Max. Continuous Discharge Current (<30min) |
100A |
| Pulse Discharge Current (<3s) |
200A |
| Cycle Life |
> 6000 cycles |
| Dimension (mm) |
Length: 323±2 Width: 171±2 Height: 232±2 |
| Weight |
12Kg |
| Charge Temperature Range |
0~45℃ |
| Discharge Temperature Range |
-20~60℃ |
| Recommended Operating Temperature |
15~35℃ |
| |
|
Built-in BMS
| No. |
Item |
Test Item |
Creterion |
| 1 |
Voltage |
Charging Voltage |
DC:14.4V CC/CV |
| Balance voltage for single cell |
3.50±0.025V |
| 2 |
Current |
Balance voltage for single cell |
35±5mA |
| Current consumption |
≤50μA |
| Maximal continuous charging current |
100A |
| Rated continuous discharging current |
100A (Peak 200A) |
| 3 |
Over charge Protection |
Over charge detection voltage for single cell |
3.65V±0.025V |
| Over charge detection delay time |
0.7S—1.3S |
| Over charge release voltage for single cell |
3.550±0.05V |
| 4 |
Over discharge Protection |
Over discharge detection voltage for single cell |
2.50V±0.07V |
| Over discharge detection delay time |
1.6±0.5S |
| Over discharge release voltage for single cell |
3.00±0.75V |
| 5 |
Over current Protection |
Over current detection current |
500±50A |
| Over current detection delay time |
1.6±0.5S |
| Release condition |
Cut load |
| 6 |
Short Protection |
Detection condition |
Exterior short circuit |
| Detection delay time |
230uS—500uS |
| Release condition |
Cut load |
| 7 |
Resistance |
Protection circuitry (MOSFET) |
≤60mΩ |
| 8 |
Temperature |
Operating Temperature Range |
-40~+85℃ |
| Storage Temperature Range |
-40~+125℃
|
Tips :
generally speaking, it is recommended to avoid hooking up LiFePO4 batteries in series to get higher voltage. If you need 24v or 36v or 48v, We can customize it for you direclty without Series connections. Because when you need to hook up 12 v lithium battery for higher voltage, what we do is to upgraded BMS inside and do some change in the standard circuit to you’re your needs. Although we can guarantee it can be hooked up to 4 batteries in series, but it is not always the best solution because it make your system more complex. But if it is a must for you to use 12v lithium battery instead of 24v or 36v or 48v directly, we can make it too. So pls contact us, advise the details requirement, our professional engineer team are here ready to help!
